Clevo P570WM

Upgrading The Computer
Upgrading the Video Card 6 - 27
6
7. Remove screws - from the heat sink in the order indicated on the heat
sink unit label (and heat sink itself).
13
18

Heat Sink Screws
Make sure you remove
the heat sink screws in
the order -
(screw
first to screw
last). This order is in-
dicated on the label (and
on the heat sink itself).
Caution
The heat sink, and video
card area in general,
contains parts which are
subject to high tempera-
tures. Allow the area
time to cool before re-
moving these parts.
Figure 6 - 31
Video Card Heat
Sink Screw Removal
13
18
13
18
13
14
15
16
1718
