Clevo P570WM

Upgrading The Computer
6 - 28 Upgrading the Video Card
6
8. Carefully pull the tab and lift with the other tab to disconnect the heat sink
from the VGA assembly.
9. Remove the heat sink unit(s) (one heat sink unit is pictured here).

Caution
The heat sink, and video
card area in general,
contains parts which are
subject to high tempera-
tures. Allow the area
time to cool before re-
moving these parts.
Figure 6 - 32
Video Card Heat
Sink Removal
19
20
21
19
20
21
