Installation check list: Functional test in harbor
7-4 Chapter 7: Installation check 99-145912-A
7.3 Installation check list: Functional test in harbor
Step Task Further information Done
1.
Check that the antenna is tracking
the satellite
The logon LED in the ACU display must be
steady green and the display must show:
TRACKING.
In the web interface and in the ACU display
check:
DASHBOARD:
System status: Tracking (see Connecting to
the web interface on page 6-1).
2.
Check that the GMU is in lock and
BUC TX on.
In the web interface check:
DASHBOARD, RX locked status must show
Locked.
The ACU display must show MDM:NETOK
3.
Connect a user PC LAN (not the
service PC) to the Internet LAN
connector 2 of the ACU.
The GMU needs no separate setup. See To
connect the ADU, ACU and GMU on page 3-26.
4.
Open a DOS window and type: ping
4.2.2.2.
Check that you get a response.
5.
Open a web browser and browse to
e.g. www.google.com.
Check that the web page is downloaded.
6.
If step 4 is successful and step 5 is
not then it seems that the DNS is
not configured correctly.
See the page SETTINGS > Network and check
the DNS setup (see To configure the LAN
network on page 6-24.
Table 7-3: Installation check list: Functional test in harbour
