Keypad and menus of the ACU
6-44 Chapter 6: Configuration 99-145912-A
Example: EVENT 1/4*: This is the first event out of a list of 4 and
there has been a change in the list. EVENT 1/4 will always
be shown, the * indicates that there has been a change.
6.4.4 Brightness of the display
To adjust the brightness do the following:
1. Press and hold OK for a short moment until BRIGHTNESS XXX% is
displayed (XXX is the current brightness value).
2. Hold OK pressed + press for lighter or for darker display.
3. Release OK to leave the brightness menu.
RX FREQUENCY Ka band receiving frequency of the active satellite,
auto-selected by modem
LNB LO 18.25 GHz, system hardware.
TX FREQUENCY Transmission frequency, auto-selected by modem
BUC LO 28.05 GHz, system hardware
LNB LO HIGH Current LNB Local Oscillator frequency, high band (GHz),
selected in the satellite profile
LNB LO LOW Current LNB Local Oscillator frequency, low band (GHz),
selected in the satellite profile
EVENT
menu
Description
<EVENT> In this menu all active events are listed. Use
and to go
through the active events.
Events can be of the type WARNING or ERROR.
If a new event occurs or there is a change in the event list while
you are in the EVENTS menu, a * is shown in the upper left corner
of the display, next to the menu name. Press OK to update the
EVENTS list, the * will be removed.
A > means the event text is longer than the display. Press > to see
the remaining text.
Table 6-20: EVENTS menu of the ACU
SATELLITE menu Description
Table 6-19: SATELLITE menu of the ACU (Continued)
