Installation of the ADU
99-145912-A Chapter 3: Installation 3-17
3.3 Installation of the ADU
The following sections describe the installation and grounding of the
ACU. The ADU is shipped fully assembled. You have to install it on the
mast and attach the ADU cable.
Before installing the ADU read the following guidelines.
WARNING! Use a strong webbed sling with a belt to lift
the ADU without damaging the radome. Make sure that
the sling can carry the ADU’s weight (126 kg).
WARNING! The ADU may be subject to swaying
motions in windy conditions. Always use tag lines to
stabilise the ADU during hoisting.
Figure 3-15: Use of strong sling with a belt and tag lines for safe hoisting
Webbed sling with belt
Tag lines
