Status signalling with LEDs and status messages
99-145912-A Chapter 8: Service & maintenance 8-11
8.4 Status signalling with LEDs and
status messages
8.4.1 Overview
8..4.1.1 Built-In Test Equipment
The ADU and the ACU have a Built-In Test Equipment (BITE) function in
order to make fault diagnostics easy during service and installation. The
BITE test is performed during:
• Power On Self Test (POST), which is automatically performed each
time the system is powered on.
• Person Activated Self Test (PAST), which is initiated by starting a self
test in the web interface HELPDESK > Self test.
For details on error messages after a POST or a self test see Event list on
page 8-3.
8..4.1.2 Means of signalling
The SAILOR 100 GX provides various methods for signalling the system
status. LEDs on the front panel of the ACU are used to signal:
• Power on/off
• Logon
•Fail/Pass
The built-in web interface of the ACU shows any events (BITE error
codes) with a short message describing each error. This is also displayed
in the ACU.
In an error situation, one of the following system status messages may
be shown:
• ACU POST error
• ADU POST error
• SAFE MODE (plus information about the specific error, see System
messages on page C-1).
During service and maintenance, one of the following system status
messages may be shown:
• Service switch
•Azimuth calibration
• TX cable calibration
• XIM data error
