COBHAM SAILOR 100 GX User Manual

99-145912-A A-1
Appendix A
Technical specifications
Technical specifications A
This appendix has the following sections:
• SAILOR 100 GX system components
• Outline drawings
A.1 SAILOR 100 GX system components
A.1.1 General specifications
Item Specification
Frequency band
Rx
Tx
Ka-Band (Inmarsat GX)
19.2 to 20.2 GHz
29.0 to 30.0 GHz
Reflector size 103 cm (40.6 inch)
Certification Compliant with CE (Maritime), ETSI, FCC
System power supply range ADU+ACU 20–32 VDC
GMU 90-264 VAC
ADU cable type (ACU to ADU) Single 50 Ohm coax cable for Rx, Tx and power
Total system power consumption 410 W peak, 200 W typical (up to 5 W BUC)
Antenna connector at the ADU Female N-Connector (50 Ohm)
Antenna connector at the ACU Female N-Connector (50 Ohm)
Table A-1: General specifications

COBHAM SAILOR 100 GX Specifications

General

Brand	COBHAM
Model	SAILOR 100 GX
Category	Marine Equipment
Language	English
