SAILOR 100 GX system components
A-4 Appendix A: Technical specifications 99-145912-A
A.1.3 ACU
Item Specification
Dimensions, rack mount
H x W x D
1U, 19 inch
4.4 x 48 x 33 cm (1.75 x 19 x 13 inch)
Weight 4.5 kg (10 lbs)
Ambient temperature Operational: -25°C to +55°C
Storage: -40°C to +85°C
Humidity EN 60945 protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.1 m (4 inch) to EN 60945
Interfaces 1 x N-Connector for antenna RF Cable (50 Ohm) with automatic cable loss
compensation
2 x F-Connectors (75 Ohm) for Rx/Tx to M
4 x Ethernet
1 x RS-422 data (modem control)
1 x RS-232 data (modem control)
1 x NMEA 0183 (RS-422 or RS-232) and prepared for NMEA 2000 for
Gyro/GPS compass input
1 x DC power input
1 x Grounding bolt
Input power 20-32 VDC, 370 W peak, 175 W typical
Modem interface (control) Generic, iDirect openAMIP protocol & custom protocol
Display and controls Web interface, OLED (red) display, 5 push buttons,
3 discrete indicator LEDs and ON/OFF switch
No transmit zones Programmable, 8 zones with azimuth and elevation
Dual antennas Dual ACU capability
Table A-3: Technical specifications for the ACU
