Site preparation
99-145912-A Chapter 3: Installation 3-5
3.2.3 Blocking zones with azimuth and elevation
Your installation may require that you set up blocking zones for the ADU,
i.e. areas where the ADU will not transmit and areas where transmit
power is potentially dangerous for persons frequently being in these
zones. You can set up 8 blocking zones. Each blocking zone is set up with
azimuth start and stop, and elevation angle. The blocking zones are set
up in the built-in web interface of the ACU during configuration. For
further information see To set up blocking zones (RX and TX) on
page 6-22.
Figure 3-2: 2 blocking zones with no-transmit zones, azimuth (example)
Figure 3-3: Blocking zone with no-transmit zones, elevation angle (example)
$QWHQQD
2EVWUXF
WLRQ
$]LPXWK
$]LPXWK
$]LPXWK
$]LPXWK
%ORFNLQJ]RQH
$]LPXWK$]LPXWK
(OHYDWLRQWR
%ORFNLQJ]RQH
$]LPXWK$]LPXWK
(OHYDWLRQWR
