Satellite profiles and VSAT modem profiles
99-145912-A Chapter 8: Service & maintenance 8-9
2. Enter or edit the Satellite profile name.
3. Select a VSAT modem profile. The page automatically displays the
parameters available for the selected VSAT modem profile. For
instructions how to add a VSAT modem profile see VSAT modem
profile – New entry and Edit on page 8-9.
4. Enter the data for the satellite, if any. For satellite data see
www.lyngsat.com.
5. Only for satellite profiles that use a VSAT modem profile
with the Generic GX modem: At Elevation cutoff enter the
minimum elevation angle for the antenna.
• FCC (FCC §25.205): 5 degrees
6. Click Apply to save the settings for the satellite profile.
8.3.2 VSAT modem profiles
On the page VSAT modem profiles you create, edit or delete VSAT
modem profiles. You must add at least one VSAT modem profile.
A VSAT modem profile contains all VSAT modem settings that are
necessary for a successful connection to the satellite. The data you have
to fill in are provided by your VSAT service and modem provider.
8..3.2.1 VSAT modem profile – New entry and Edit
To add or edit a VSAT modem profile, do as follows:
1. Go to SETTINGS > VSAT modem profiles and click New entry or
Edit. The supported VSAT modem profiles are listed in the drop-
down list VSAT modem profile.
It is helpful to assign a name containing the location where
the Satellite profile is to be used (e.g. Gulf of Mexico or
North Sea) and possibly the provider.
Figure 8-7: Web interface: SETTINGS, VSAT modem profiles (example)
