SAILOR 100 GX system components
99-145912-A Appendix A: Technical specifications A-5
A.1.4 GMU
A.1.5 Patents
Item Specification
Dimensions, rack mount
H x W x D
1U, 19 inch
4.4 x 48 x 33 cm (1.75 x 19 x 13 inch)
Weight 4.5 kg (10 lbs)
Ambient temperature Operational: -25°C to +55°C
Storage: -40°C to +85°C
Humidity IEC 60945 protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.1 m (4 inch) to IEC 60945
Modem type Based on iDirect/Inmarsat GX Core Module
Interfaces 2 x F-Connectors (75 Ohm) for Rx/Tx to ACU
1 x LAN connector for control and user data (routes through ACU)
1 x RS-422 data (Modem control)
1 x RS-232 data (Modem control)
1 x RS-232 modem console
1 x universal AC input
1 x Grounding bolt
Input power 100-240 VAC
Modem interface (control) iDirect openAMIP protocol, RS-422 & RS-232
Display Web interface, power LED and ON/OFF switch
Temperature control Built-in fan and heater
Table A-4: Technical specifications for the GMU
Patent application number Description
11749202.5; 10-2013-
7008607; 13/819,621
An assembly comprising a movable and brakable/dampable part and a
method for braking a movable part
PCT/EP2012/063849 Combined antennas without switch
Currently applying Reflector with enforcement ring
Table A-5: Patents
