Configuration with the web interface
99-145912-A Chapter 6: Configuration 6-27
The default gateway can be set as a static IP address. Then set the
default gateway source to static and enter the IP address of the default
gateway. To remove the default gateway set it to 0.0.0.0.
Alternatively, if your DHCP server is able to provide a default gateway
address and you have selected DHCP client above, then select the same
LAN as your default gateway source.
Zeroconf Settings
On LAN ports 1,3 and 4 you can choose to add a zeroconf address in the
network (169.254.0.0).This zeroconf address will be in addition to the
existing static or DHCP IP address. One port at a time can be enabled.
Zeroconf allows devices to connect to a network automatically.
VLAN port membership table
The VLAN port membership table is configured by the GMU. The table is
useful when troubleshooting.
6.3.4 E-mail setup
To be able to send diagnostics and statistics reports through an external
Internet connection using e-mail you must set up a couple of
parameters. Contact your IT department for the specific data.
To configure the e-mail setup, do the following:
1. Go to SETTINGS > E-mail setup.
2. Enter the data for Outgoing mail server (SMTP), SMTP port number,
SMTP authentication, User name and password. This data is typically
provided by your IT department.
Figure 6-19: Web interface: SETTINGS, E-mail setup (example)
You must set Outgoing mail server to an IP address if
DNS has not been set up in DNS setup in To configure the
LAN network on page 6-24.
