COBHAM SAILOR 100 GX User Manual

SAILOR 100 GX system components
99-145912-A Appendix A: Technical specifications A-3
Technical specifications
Wind resistance Operational: 80 kt.
Survival: 110 kt.
Ice Survival: 25 mm (1 inch)
Solar radiation 1120 W/m
2
to MIL-STD-810F 505.4
Compass safe distance 100 cm to EN 60945
Maintenance, scheduled None (T
amb
>10°C)
Maintenance, unscheduled All electronic, electromechanical modules and belts can be
replaced through the service hatch.
Built-in tests Power On Self Test (POST)
Person Activated Self Test (PAST)
Continuous Monitoring (CM) with error log
Power OFF Automatic safe mode
Input power Powered by ACU
Dimensions (overall) Diameter x Height: Ø 130 cm (51.3 inch) x H 150 cm (58.9 inch)
Weight, ADU 126 kg (276 lbs)
Item Specification
Table A-2: Technical specifications for the Above Deck Unit (Continued)

COBHAM SAILOR 100 GX Specifications

General

Brand	COBHAM
Model	SAILOR 100 GX
Category	Marine Equipment
Language	English
