COBHAM SAILOR 100 GX User Manual

Keypad and menus of the ACU
99-145912-A Chapter 6: Configuration 6-43
Configuration
SIGNAL
LEVEL
Current input signal level from the GMU
Signal level in dB
NET LED LED indication from GMU. Steady or flashing green/amber/red,
OFF
STAT LED
TX LED
RX1 LED
RX2 LED
PWR LED
TEMP LED
FAN LED
MODEM
menu
Description
Table 6-17: MODEM menu of the ACU (Continued)
NETWORK menu Description
PORT 1 IP Current IP address for LAN 1
MASK 1 Current netmask for LAN 1
PORT 3 IP (LAN 3) Current IP address of the SAILOR 100 GX web
interface (default: http://192.168.0.1)
MASK 3 (LAN 3) Current netmask of the SAILOR 100 GX web
interface (default: 255.255.255.0)
PORT 4 IP Current IP address for LAN 4
MASK 4 Current netmask for LAN 4
DEFAULT GATEWAY Current default gateway
Table 6-18: NETWORK menu of the ACU
SATELLITE menu Description
POSITION Position of the current satellite
RX POLARISATION LHC or RHC
TX POLARIZATION X-POL or CO-POL
Table 6-19: SATELLITE menu of the ACU
