Keypad and menus of the ACU
6-42 Chapter 6: Configuration 99-145912-A
Menu descriptions
NETWORK IP addresses and netmasks of the LAN connectors of the ACU
and the management mask.
SATELLITE Current satellite information. This information is selected
using the web interface.
EVENTS System events. Active events are shown as: X ACTIVE
EVENTS in the MAIN display. Press OK to update the list.
Top-level
menu
Description
Table 6-15: Top-level menus of the ACU (Continued)
ANTENNA
menu
Description
POINTING ANTENNA STATE: Current state of the antenna, e.g.
TRACKING
ELEVATION: Current elevation angle of the antenna
AZIMUTH: Current azimuth of the antenna, with reference to
North
POLARISATION RX POLARISATION: LHC or RHC.
TX POLARIZATION: X-POL or Co-POL.
GPS LATITUDE: current latitude, read from GPS module.
LONGITUDE: current longitude, read from GPS module.
FIX TYPE: 2D or 3D or NONE
HEADING Ship’s heading in degrees with reference to North, provided
by the ship’s gyro
VERSIONS Current software version
SERIAL
NUMBERS
ACU: ACU serial number
ADU: Serial number of the antenna
Table 6-16: ANTENNA menu of the ACU
MODEM
menu
Description
MODEM
TYPE
Connected modem type
TX ENABLE On or off, information delivered by the connected GMU
RX LOCK On or off, information delivered by the connected GMU
Table 6-17: MODEM menu of the ACU
