List of ADU events
C-6 Appendix C: System messages 99-145912-A
0A053-0 Antenna ERROR ISM
communication
Communication error between PCM and ISM.
Check SUB-D connectors and cables.
0A054-0 Antenna ERROR PMM
communication
Communication error between PCM and PMM.
Check SUB-D connectors and cables.
0A055-0 Antenna WARNING Azi DDM warning The azimuth motor controller has temporarily
observed an unusual situation with regards to
temperature, voltage, current or velocity. No
user interaction required.
0A056-0 Antenna WARNING Xel DDM warning The cross-elevation motor controller has
temporarily observed an unusual situation with
regards to temperature, voltage, current or
velocity. No user interaction required.
0A057-0 Antenna WARNING Ele DDM warning The elevation motor controller has temporarily
observed an unusual situation with regards to
temperature, voltage, current or velocity. No
user interaction required.
0A058-0 Antenna WARNING PMM warning The polarisation motor controller has
temporarily observed an unusual situation with
regards to temperature, voltage, current or
velocity. No user interaction required.
0A059-0 Antenna WARNING Azi cal. limits Azimuth axis calibration result check limits
exceeded. Pointing performance may be
degraded. Info:
0x00000040: End stop detected before
expected limit
0x00000100: Zero width is low
0x00000200: Zero width is high
0x00000400: Zero slack is high
0x00001000: Friction average is high
0x00002000: Friction peak is high
0x00004000: Friction asymmetry is high
Zero width low/high: Zero reference module
placement may be incorrect.
Zero slack high: Mechanical slack may be too
high.
Friction average/peak high: Mechanical friction
is higher than expected.
Friction asymmetry high: Mechanical imbalance
may be too high.
Error
code
(ID)
Unit Severity Description Explanation
Table C-1: ADU event messages (Continued)
