Page #234 background imageLoading...
Page #234 background image
Supported commands
D-6 Appendix D: Command line interface 99-145912-A
satellite tx_pol
satellite tx_pol v
Shows or sets the current TX polarisation:
•v (vertical)
h (horizontal)
•l (left)
•r (right)
satellite ele_cut_off
satellite ele_cut_off 5
Shows or sets the elevation referenced to earth
where the SAILOR VSAT system must shut off for
transmission. This is an FCC requirement. The
elevation cut off depends on how much power is
transmitted and which coding is used.
•Valid range: 0° to 90°
satellite rx_lo
Shows the Rx LO / LNB LO.
Range: 9.6 GHz to 11.3 GHz.
GX: 18.25 GHz
satellite rx_rf_freq
satellite rx_rf_freq
12.123456 9.75
Shows or sets the Rx frequency and LNB Lo
frequency.
•Ku band:
RF frequency: 10.7 – 12.75 GHz.
LNB Lo frequency: 9.6 GHz – 11.3 GHz.
The SAILOR VSAT system supports any LNB Lo.
•Ka band:
RF frequency: 19.2 – 20.2 GHz.
LNB Lo frequency: 18.25 GHz.
Note: Setting the Ku-band Rx frequency and LNB
Lo automatically configures the L-band rx
frequency:
Rx L-band freq = rx_rf_freq – LNB Lo
Example: 1567.890 MHz = 11.567890 GHz –
10 GHz
Command Description
Table D-8: UCLI command: satellite (Continued)
