Section 7: Setting Measurement Options
74
Units Spectrum
Scaling
Time Waveform Scaling
Accel
g, m/s
2
RMS, 0-
pk,
pk-pk
RMS, 0-pk, pk-pk
Veloc
mm/s, in/s As above As above
Disp
mm, µm, mil As above As above
Unit Set SI US Custom
Frequency
Hz CPM Hz, CPM
vdB Units
vdB SI (1e-6 mm/s)
vdB US (1e-5 mm/s)
vdB US, vdB SI
adB Units
adB SI (1 µm/s
2
) adB US (1 µg) adB US, adB SI
Linear
Speed
Distance
mm in mm, in
Weight
g, kg lb, oz
lb, oz, tons, kg,
g
Balancing Units
Quantity Acceleration Velocity Displacement
Units
g in/s, mm/s mm, µm, mil
Scaling
RMS, 0-pk, pk-pk
