ComNav P4 Installation and Operation
Document PN 29010100 V1r0 - 59 -
Figure 33 – Wiring Connections for Reversing DC Motors
Linear Actuators or Mechanical Rotary Drives
Some Linear Actuators incorporate a bypass valve. To operate properly, the bypass valve
should be activated by the SW’D B+ output on the SPU. Similarly, most mechanical drives
incorporate a solenoid-activated clutch. The clutch solenoid should also be activated by the
SW’D B+ output. Refer to the following diagram in Figure 34:
Figure 34 – Wiring Connections for Linear Actuators or Mechanical Rotary Drives
