INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 104
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
MLD Snooping
Basic Configuration
This page provides MLD Snooping related configuration.
Object Description
Snooping Enable Enable the Global MLD Snooping.
Unregistered IPMCv6
Flooding Enable
Enable unregistered IPMCv6 traffic flooding.
The flooding control takes effect only when MLD Snooping is enabled.
When MLD Snooping is disabled, unregistered IPMCv6 traffic flooding is always active in
spite of this setting.
MLD SSM Range SSM (Source-Specific Multicast) Range allows the SSM-aware hosts and routers run the SSM
service model for the groups in the address range.
Leave Proxy Enable Enable MLD Leave Proxy. This feature can be used to avoid forwarding unnecessary leave
messages to the router side.
Proxy Enable Enable MLD Proxy. This feature can be used to avoid forwarding unnecessary join and leave
messages to the router side.
Router Port Specify which ports act as router ports. A router port is a port on the Ethernet switch that
leads towards the Layer 3 multicast device or MLD querier.
If an aggregation member port is selected as a router port, the whole aggregation will act
as a router port.
Fast Leave Enable the fast leave on the port.
Throttling Enable to limit the number of multicast groups to which a switch port can belong.
Apply Click to apply changes.
Reset Click to revert to previous values.
