INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 103
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Port Filtering Profile
Object Description
Port The logical port for the settings.
Filtering Profile Select the IPMC Profile as the filtering condition for the specific port. Summary about the
designated profile will be shown by clicking the view button.
Profile Management
Button
You can inspect the rules of the designated profile by using the following button
“Eye”: List the rules associated with the designated profile.
Apply Click to apply changes.
Reset Click to revert to previous values.
