INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 114
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Command None: There is no active local command on this instance.
Clear: The active local command will be cleared.
Lock Out: This EPS is locked to working (not active). In case of 1:N (more than one EPS with same
protecting flow) - when one EPS switch to protecting flow, other EPS is enforced this command
Forced Switch: Forced switch to protecting.
Manual Switch P: Manual switch to protecting.
Manual Switch W: Manual switch to working. This is only allowed in case of 'non-revertive' mode
Exercise: Exercise of the protocol - not traffic effecting. This is only allowed in case of
'Bidirectional' protection type
Freeze: This EPS is locally freezed - ignoring all input.
Lock Out Local: This EPS is locally "locked out" - ignoring local SF detected on working.
Instance State
Protection State EPS state according to State Transition Tables in G.8031.
W Flow OK: State of working flow is ok
SF: State of working flow is Signal Fail
SD: State of working flow is Signal Degrade (for future use)
P Flow OK: State of protecting flow is ok
SF: State of protecting flow is Signal Fail
SD: State of protecting flow is Signal Degrade (for future use)
Transmit APS r/b The transmitted APS according to State Transition Tables in G.8031.
Receive APS r/b The received APS according to State Transition Tables in G.8031.
Architecture
Mismatch
The architecture indicated in the received APS does not match the locally configured.
APS on working APS is received on the working flow.
Switching
Incomplete
Traffic is not selected from the same flow instance in the two ends.
No APS Received APS PDU is not received from the other end.
Refresh Click to refresh the page immediately.
Apply Click to apply changes.
Reset Click to undo any changes made locally and revert to previously saved values.
