Object Description
Tag Class. Shows the classification mode for tagged frames on this port.
Disabled: Use default CoS and DPL for tagged frames.
Enabled: Use mapped versions of PCP and DEI for tagged frames.
Click on the mode in order to configure the mode and/or mapping.
Note: This setting has no effect if the port is VLAN unaware. Tagged frames received on VLAN
unaware ports are always classified to the default CoS and DPL.
DSCP Based Click to Enable DSCP Based QoS Ingress Port Classification.
Address
Mode
The IP/MAC address mode specifying whether the QCL classification must be based on source (SMAC/
SIP) or destination (DMAC/DIP) addresses on this port. The allowed values are:
Source: Enable SMAC/SIP matching.
Destination: Enable DMAC/DIP matching.
Apply Click to apply changes.
Reset Click to revert to previous values.
