Object Description
Port Shaper Rate Controls the rate for the port shaper. This value is restricted to 100-3281943 when "Unit" is
kbps, and 1-3281 when "Unit" is Mbps. Only shown for Non-service configuration. The rate
is internally rounded up to the nearest value supported by the port shaper.
Port Shaper Unit Controls the unit of measure for the port shaper rate as kbps or Mbps. Only shown for Non-
service configuration.
HQoS Shaper Enable Controls whether the HQoS shaper is enabled for this HQoS ID. Only shown when
configuring HQoS entries.
HQoS Shaper Rate Controls the rate for the HQoS shaper. This value is restricted to 100-3281943 when "Unit"
is kbps, and 1-3281 when "Unit" is Mbps. Only shown when configuring HQoS entries. The
rate is internally rounded up to the nearest value supported by the HQoS shaper.
HQoS Shaper Unit Controls the unit of measure for the HQoS shaper rate as kbps or Mbps. Only shown when
configuring HQoS entries.
Guaranteed Bandwidth
Enable
Controls whether the HQoS guaranteed bandwidth is enabled for this HQoS ID. Only shown
when configuring HQoS entries.
Guaranteed Bandwidth
Rate
Controls the rate for the guaranteed bandwidth. This value is restricted to 0-3281943
when "Unit" is kbps, and 0-3281 when "Unit" is Mbps. Only shown when configuring HQoS
entries.
Guaranteed Bandwidth
Unit
Controls the unit of measure for the guaranteed bandwidth as kbps or Mbps. Only shown
when configuring HQoS entries.
Apply Click to apply changes.
Reset Click to undo any changes made locally and revert to previously saved values.
Back Click to undo any changes made locally and return to the previous page.
