INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 158
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
QoS Egress Port Tag Remarking Configuration
The QoS Egress Port Tag Remarking for a specific port are configured on this page.
Object Description
Mode Controls the tag remarking mode for this port.
Classified: Use classified PCP/DEI values.
Default: Use default PCP/DEI values.
Mapped: Use mapped versions of QoS class and DP level.
PCP/DEI Configuration Controls the default PCP and DEI values used when the mode is set to Default.
(QoS class, DP level) to
(PCP, DEI) Mapping
Controls the mapping of the classified (QoS class, DP level) to (PCP, DEI) values when the
mode is set to Mapped.
Apply Click to apply changes.
Reset Click to undo any changes made locally and revert to previously saved values.
Cancel Click to undo any changes made locally and return to the previous page.
