INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 166
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Storm Policing
Storm control for the switch is configured on this page.
There is a unicast storm rate control, multicast storm rate control, and a broadcast storm rate
control. These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on
the MAC Address table.
The configuration indicates the permitted packet rate for unicast, multicast or broadcast traffic
across the switch.
Object Description
Frame Type The settings in a particular row apply to the frame type listed here: Unicast, Multicast or Broadcast.
Enable Enable or disable the storm control status for the given frame type.
Rate The rate unit is packets per second (pps). Valid values are: 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1K, 2K,
4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K or 1024K.
Apply Click to apply changes.
Reset Click to revert to previous values.
