Object Description
Destination The switch is an end node for monitor flow.
The destination port(s) and intermediate port(s) are located on this switch.
VLAN ID The VLAN ID points out where the monitor packet will copy to. The default VLAN ID is 200.
Reflector Port The reflector port is a method to redirect the traffic to Remote Mirroring VLAN. Any device
connected to a port set as a reflector port loses connectivity until the Remote Mirroring is disabled.
In the stacking mode, you need to select switch ID to select the correct device.
If you shut down a port, it cannot be a candidate for reflector port.
If you shut down the port which is a reflector port, the remote mirror function cannot work.
Note1: The reflector port needs to select only on Source switch type.
Note2: The reflector port needs to disable MAC Table learning and STP.
Note3: The reflector port only supports on pure copper ports.
Source VLAN(s)
Configuration
The switch can supports VLAN-based Mirroring. If you want to monitor some VLANs on the switch,
you can set the selected VLANs on this field.
Note1: The Mirroring session shall have either ports or VLANs as sources, but not both.
Remote Mirroring Port Configuration
Port The logical port for the settings contained in the same row.
Source Select mirror mode.
Disabled Neither frames transmitted nor frames received are mirrored.
Both Frames received and frames transmitted are mirrored on the Intermediate/Destination port.
Rx only Frames received on this port are mirrored on the Intermediate/Destination port. Frames
transmitted are not mirrored.
Tx only Frames transmitted on this port are mirrored on the Intermediate/Destination port. Frames
received are not mirrored.
Intermediate Select intermediate port.
This checkbox is designed for Remote Mirroring.
The intermediate port is a switched port to connect to other switch.
Note: The intermediate port needs to disable MAC Table learning.
Destination Select destination port.
This checkbox is designed for mirror or Remote Mirroring.
The destination port is a switched port that you receive a copy of traffic from the source port.
Note1: On mirror mode, the device only supports one destination port.
Note2: The destination port needs to disable MAC Table learning.
