INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 187
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Rx Drops The number of frames dropped due to lack of receive buffers or egress congestion.
Rx CRC/Alignment The number of frames received with CRC or alignment errors.
Rx Undersize The number of short 1 frames received with valid CRC.
Rx Oversize The number of long 2 frames received with valid CRC.
Rx Fragments The number of short 1 frames received with invalid CRC.
Rx Jabber The number of long 2 frames received with invalid CRC.
Rx Filtered The number of received frames filtered by the forwarding process.
1 Short frames are frames that are smaller than 64 bytes.
2 Long frames are frames that are longer than the configured maximum frame length for this
port.
Transmit Error Counters
Tx Drops The number of frames dropped due to output buffer congestion.
Tx Late/Exc. Coll The number of frames dropped due to excessive or late collisions.
Port1 Click to select the port.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Clear Click to clear the counters for the selected port.
Refresh Click to refresh the page.
