Port
This page provides detailed NAS statistics for a specific switch port running EAPOL-based
IEEE 802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS
Authentication Server) statistics, only .
Use the port select box to select which port details to be displayed.
Object Description
Admin State The port’s current administrative state. Refer to NAS Admin State for a description of possible
values.
Port State The current state of the port. Refer to NAS Port State for a description of the individual states.
QoS Class The QoS class assigned by the RADIUS server. The field is blank if no QoS class is assigned.
Port VLAN ID The VLAN ID that NAS has put the port in. The field is blank, if the Port VLAN ID is not overridden
by NAS.
If the VLAN ID is assigned by the RADIUS server, “(RADIUS-assigned)” is appended to the VLAN ID.
If the port is moved to the Guest VLAN, “(Guest)” is appended to the VLAN ID.
Port1 Click to select the port.
Auto_refresh Check to refresh the page automatically every 3 seconds.
Refresh Click to refresh the page.
