INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 45
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Click on “Add New Entry”.
The SNMP Trap Configuration page includes the following fields:
Object Description
Trap Mode Indicates the SNMP trap mode operation. Possible modes are: Enabled: Enable SNMP trap mode
operation. Disabled: Disable SNMP trap mode operation.
Trap Version Indicates the SNMP trap supported version. Possible versions are: SNMP v1: Set SNMP trap
supported version 1. SNMP v2c: Set SNMP trap supported version 2c. SNMP v3: Set SNMP trap
supported version 3.
Trap Community Indicates the community access string when sending SNMP trap packet. The allowed string length
is 0 to 255, and the allowed content is ASCII characters from 33 to 126.
Trap Destination
Address
Indicates the SNMP trap destination address. It allows a valid IP address in dotted decimal notation
(‘x.y.z.w’).
And it also allows a valid hostname. A valid hostname is a string drawn from the alphabet (A-Za-z),
digits (0-9), dot (.), dash (-). Spaces are not allowed, the first character must be an alpha character,
and the first and last characters must not be a dot or a dash
Trap Link-up and
Link-down
Indicates the SNMP trap link-up and link-down mode operation. Possible modes are: Enabled:
Enable SNMP trap link-up and link-down mode operation. Disabled: Disable SNMP trap link-up and
link-down mode operation.
Trap Destination
Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message via this port, the
port range is 1~65535.
