INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 44
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
SNMP Trap
Configure SNMP trap on this page.
Object Description
Global Settings
Mode Indicates the trap mode operation. Possible modes are: Enabled: Enable SNMP trap mode
operation. Disabled: Disable SNMP trap mode operation.
Trap Destination Configurations
Name Indicates the trap Configuration’s name. Indicates the trap destination’s name.
Enable Indicates the trap destination mode operation. Possible modes are: Enabled: Enable SNMP trap
mode operation. Disabled: Disable SNMP trap mode operation.
Version Indicates the SNMP trap supported version. Possible versions are: SNMPv1: Set SNMP trap
supported version 1. SNMPv2c: Set SNMP trap supported version 2c. SNMPv3: Set SNMP trap
supported version 3.
Destination
Address
Indicates the SNMP trap destination address. It allows a valid IP address in dotted decimal
notation (‘x.y.z.w’).
And it also allows a valid hostname. A valid hostname is a string drawn from the alphabet
(A-Za-z), digits (0-9), dot (.), dash (-). Spaces are not allowed, the first character must be an alpha
character, and the first and last characters must not be a dot or a dash.
Indicates the SNMP trap destination IPv6 address. IPv6 address is in 128-bit records represented
as eight fields of up to four hexadecimal digits with a colon separating each field (:). For
example, ‘fe80::215:c5ff:fe03:4dc7’. The symbol ‘::’ is a special syntax that can be used as a
shorthand way of representing multiple 16-bit groups of contiguous zeros; but it can appear only
once. It can also represent a legally valid IPv4 address. For example, ‘::192.168.10.1’.
Destination port Indicates the SNMP trap destination port. SNMP Agent will send SNMP message via this port,
the port range is 1~65535.
