INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 74
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
ICMP Code
Filter
Specify the ICMP code filter for this ACE.
Any: No ICMP code filter is specified (ICMP code filter status is “don’t-care”). Specific: If you want to
filter a specific ICMP code filter with this ACE, you can enter a specific ICMP code value. A field for
entering an ICMP code value appears.
ICMP Code
Value
When “Specific” is selected for the ICMP code filter, you can enter a specific ICMP code value. The
allowed range is 0 to 255. A frame that hits this ACE matches this ICMP code value.
TCP/UDP Parameters
TCP/UDP
Source Filter
Specify the TCP/UDP source filter for this ACE.
Any: No TCP/UDP source filter is specified (TCP/UDP source filter status is “don’t-care”).
Specific: If you want to filter a specific TCP/UDP source filter with this ACE, you can enter a specific
TCP/UDP source value. A field for entering a TCP/UDP source value appears.
Range: If you want to filter a specific TCP/UDP source range filter with this ACE, you can enter a
specific TCP/UDP source range value. A field for entering a TCP/UDP source value appears.
TCP/UDP
Source No.
When “Specific” is selected for the TCP/UDP source filter, you can enter a specific TCP/UDP source
value. The allowed range is 0 to 65535. A frame that hits this ACE matches this TCP/UDP source value.
TCP/UDP
Source Range
When “Range” is selected for the TCP/UDP source filter, you can enter a specific TCP/UDP source
range value. The allowed range is 0 to 65535. A frame that hits this ACE matches this TCP/UDP source
value.
TCP/UDP
Destination
Filter
Specify the TCP/UDP destination filter for this ACE.
Any: No TCP/UDP destination filter is specified (TCP/UDP destination filter status is “don’t-care”).
Specific: If you want to filter a specific TCP/UDP destination filter with this ACE, you can enter a
specific TCP/UDP destination value. A field for entering a TCP/UDP destination value appears.
Range: If you want to filter a specific range TCP/UDP destination filter with this ACE, you can enter a
specific TCP/UDP destination range value. A field for entering a TCP/UDP destination value appears.
TCP/UDP
Destination
Number
When “Specific” is selected for the TCP/UDP destination filter, you can enter a specific TCP/UDP
destination value. The allowed range is 0 to 65535. A frame that hits this ACE matches this TCP/UDP
destination value.
TCP/UDP
Destination
Range
When “Range” is selected for the TCP/UDP destination filter, you can enter a specific TCP/UDP
destination range value. The allowed range is 0 to 65535. A frame that hits this ACE matches this TCP/
UDP destination value.
TCP FIN Specify the TCP “No more data from sender” (FIN) value for this ACE. 0: TCP frames where the FIN
field is set must not be able to match this entry. 1: TCP frames where the FIN field is set must be able
to match this entry. Any: Any value is allowed (“don’t-care”).
TCP SYN Specify the TCP “Synchronize sequence numbers” (SYN) value for this ACE. 0: TCP frames where the
SYN field is set must not be able to match this entry. 1: TCP frames where the SYN field is set must be
able to match this entry. Any: Any value is allowed (“don’t-care”).
TCP RST Specify the TCP “Reset the connection” (RST) value for this ACE.
0: TCP frames where the RST field is set must not be able to match this entry. 1: TCP frames where the
RST field is set must be able to match this entry. Any: Any value is allowed (“don’t-care”).
TCP PSH Specify the TCP “Push Function” (PSH) value for this ACE.
0: TCP frames where the PSH field is set must not be able to match this entry. 1: TCP frames where
the PSH field is set must be able to match this entry. Any: Any value is allowed (“don’t-care”).
TCP ACK Specify the TCP “Acknowledgment field significant” (ACK) value for this ACE. 0: TCP frames where the
ACK field is set must not be able to match this entry. 1: TCP frames where the ACK field is set must be
able to match this entry. Any: Any value is allowed (“don’t-care”).
