INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 94
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Port The switch port number of the corresponding STP CIST (and MSTI) port.
Path Cost Controls the path cost incurred by the port. The Auto setting will set the path cost as appropriate by the
physical link speed, using the 802.1D recommended values. Using the Specific setting, a user-defined
value can be entered. The path cost is used when establishing the active topology of the network.
Lower path cost ports are chosen as forwarding ports in favor of higher path cost ports. Valid values are
in the range 1 to 200000000.
Priority Controls the port priority. This can be used to control priority of ports having identical port cost. (See
above).
Apply Click to apply changes.
Reset Click to revert to previous values.
Get Click to retrieve settings for a specific MSTI.
