3033-003B Section 3: Electrical
Concordia Xpress Technical Support Manual 3-13
2900-300B
Flavor System
Water Valve: 24Vdc x1
Peristaltic Pump: 24Vdc, 282rpm x6
All flavor tubes are color-coded.
Syrup Driver Power: 115Vac
Chocolate Heater Assembly: 115Vac
Software Sub-
Category
Color Code
Corresponding Flavor
Small Flavor 1
Black
Chocolate
Large Flavor 1
Small Flavor 2
Yellow
Caramel
Large Flavor 2
Small Flavor 3
White
Vanilla
Large Flavor 3
Small Flavor 4
Red
Chai
Large Flavor 4
Small Flavor 5
Green
Hazelnut
Large Flavor 5
Small Flavor 6
Blue
Sugar-Free Vanilla
Large Flavor 6
For additional information on the flavor system, please see Section 9:
Flavor System.
