Electrical Enclosure
Located behind the left door, the electrical enclosure houses:
Power switch
AC drawer
DC power supply board
LED display on DC power supply
CPU boards
LED display on CPU
CPU buttons
Backplane
Line voltage test receptacle
Electrical enclosure fan
