1.8.3.3 Tubing Sets (E9416/E9417) for use with 3.7 mm and 4.2 mm Irrigated Shaver
Blades
The E9416 (4.2 mm) and E9417 (3.7 mm) Tubing Sets are used to provide irrigation to irrigated
shaver blades and burs.
1. Spike Line — Connects to the fluid supply for fluid distribution to the surgical site.
2. Cassette — Attaches to the peristaltic pump of the controller to aid in fluid delivery.
3. Handpiece Cord Clips — Used to attach the tubing to the handpiece cord.
4. Irrigation Collar — Attaches to the blade hub to allow fluid distribution to the surgical site.
❹
❶
❷
❸
E9416/E9417 Tubing Set
