37
CONTROLLER
OPERATION
A
2.1.3.1 Controller Options/Function Switch Settings
The Advantage, E9000 and Power
Pro System option/function switches allow the user to set several
operating parameters. All switch settings are initially set to “OFF” when shipped from the factory and
function as follows in this position:
E9000 and Advantage Controller Top DIP Switch Settings
Switch 1: Selects “Day-to-Day” Memory. Factory set to Memory off (See page 39).
Switch 2: Selects the footswitch mode of operation - Variable Speed or ON/OFF mode.
Factory set to Variable Speed mode (See page 40).
Switch 3: Selects whether Audio is on or off. Factory set to off (See page 40).
Switch 4: Selects the Handpiece Oscillation setting, Single or Multi-turn oscillation mode.
Factory set to Single-turn oscillate mode (See page 43).
When using an Advantage Turbo Handpiece (D9920/D9924) this switch selects
the Handpiece Oscillation setting, Fixed Multi-turn or Adjustable Multi-turn
oscillation mode. In Fixed Multi-turn, oscillations are set to 5 turns. In
Adjustable Multi-turn, oscillations can be adjusted by the user between 1 and 10.
Factory set to Fixed Multi-turn oscillate (5 turns) mode (See page 43).
Switch 5: Selects Window Indexing. Factory set to Window Indexing off (See page 44).
Switch 6: Selects the default speed of the Advantage D9820, D9920, D9824, and D9924
Shavers when using a high speed bur. With this switch set to “ON” default speed
is the maximum handpiece speed With this switch set to “OFF” default speed is
7K rpm. Factory set to off, handpiece default speed at 7K rpm (See page 45).
Switch 7: Selects whether the shaver handpiece buttons are enabled or disabled. Factory set
to off, buttons enabled (See page 46).
Switch 8: No application.
