CONTROLLER
OPERATION
50
A
1. Place the Irrigation Pump on top of the
controller in the defined footrest area.
2. Plug the power cord into the back of the
Irrigation Pump and a standard, grounded
wall outlet.
3. Insert the Irrigation Cord connector into the
“ELECTRIC INPUT” receptacle on the
front of the Irrigation Pump.
4. Insert the other end of the Irrigation Cord
connector into the “IRRIGATION”
receptacle on the back of the Power
Pro
controller.
5. Attach the irrigation hanger and solution
bag to the pump.
6. Fully assemble the Irrigation Tubing to the
Irrigation Pump.
7. Attach the proper Irrigation Tips
and Tubing to the handpiece. For
additional information refer to
the Hall Irrigation System Instruction
Manual.
