SETUP Assembling the Cubiscan 325

Cubiscan 325 10

3. Secure the gate to the gate tray using the eight Phillips screws

provided. The four slot screws may already be screwed into the gate, if

they are, you only need to screw four Phillips screws into place.

Figure 5

Red brackets

Figure 6

Gate screws
