CALIBRATION Calibrating the gate

Cubiscan 325 55

Calibrating the gate

To calibrate the gate using the touchscreen, proceed as follows.

1. Tap MENU at the home screen.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

Figure 51

Home screen
