CONFIGURATION System configuration

Cubiscan 325 49

1. From the home screen, tap MENU.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

2. Tap CONFIGURE. Select the Other option if it is not already selected.

Figure 44

Home screen

Figure 45

Configure other
