TROUBLESHOOTING Diagnostics

Cubiscan 325 72

Gate diagnostics

Complete the following steps to view the gate diagnostics.

1. From the home screen, tap MENU.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

Figure 67

Home screen
