SETUP Connecting to a computer or network (optional)
Cubiscan 325 17
• Connect the Cubiscan 325 to a PC through the RS-232-C serial port on
the controller box. Use the Qbit software on the computer to run the
Cubiscan 325.
• Operate the Cubiscan 325 without a computer using the touchscreen.
Refer to “Measuring/Weighing items” on page 30 for information.
Connecting to a computer via Ethernet
This section describes how to use Ethernet to connect a computer to the
Cubiscan 325 (recommended method).
Use Cubiscan’s Qbit software (refer to the Qbit User Guide) or the
touchscreen options (see CHAPTER 4 “CONFIGURATION”) to configure
the Cubiscan 325 for TCP/IP communication. Contact Cubiscan if you need
additional assistance.
If you are using the Ethernet connection option:
1. Install the driver that is needed, for further information on installing the
driver, see below.
2. Connect the Ethernet cable (supplied) to the Cubiscan 325’s Ethernet
port, as shown in Figure 14.
3. Attach the Ethernet cable to the TRENDnet USB to Ethernet cable
adapter (supplied).
4. Connect the TRENDnet cable adapter to the PC.
NOTE
The following screen images were taken from a Windows 7 operating system. Your
screen images may appear different if you are using a different operating system.
The Cubiscan is compatible with later versions of Windows, including Windows 11.
Figure 14
Ethernet, serial, and USB connectors
Serial
Ethernet
USB
