TROUBLESHOOTING About

Cubiscan 325 66

1. Tap MENU at the home screen.

2. Tap About. Select the Version option if it is not already selected.

MAC

This field displays the Media Access Control (MAC) address.

This field displays the product number that is unique to each Cubiscan 325.

Figure 59

Home screen

Figure 60

About version
