CubiScan 325 - Figure 33 Home Screen; Figure 34 Configure Operation

97 pages

Save Page as PDF

To Next Page

To Previous Page

1. From the home screen, tap MENU.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

2. Tap CONFIGURE. Select the Operation option if it is not already

selected.

Figure 33

Home screen

Figure 34

Configure operation
