SETUP Connecting to a computer or network (optional)
Cubiscan 325 16
3. Turn on the Cubiscan 325 with the power switch located on the right
side of the controller box.
4. Zero the Cubiscan 325. For instructions, See “Zeroing the Cubiscan
325” on page 32.
The Cubiscan 325 performs self-calibration and diagnostic procedures that
take about 5 seconds. Do not touch the Cubiscan 325 platform during
these 5 seconds.
Connecting to a computer or network
(optional)
To connect the Cubiscan 325 to a computer, do the following.
1. Place the computer close to the Cubiscan 325. (Refer to “Placement”
on page 7 for information.)
2. Remove the center cover by removing the two thumb screws located
on the right-hand side of the cover. Slide the cover off to the left so that
you can access the ports on the left side of the controller.
3. Locate the controller box. The controller box can be found beneath the
measuring gate’s home position (the right-hand side).
4. Choose from one of the following operating methods.
• Connect the Cubiscan 325 to a host system via a standard 10/100Base-T
Ethernet TCP/IP port. This is the recommended method and all parts
needed to connect the Cubiscan 325 to a computer via an Ethernet
connection have been supplied by Cubiscan. You may need to load the
driver. To load the driver onto the computer follow the instructions on
page 18. You can use Qbit software or the touchscreen options to
configure the Cubiscan 325 for TCP/IP communication. Contact
Cubiscan for information on available software. Or, refer to the
Communications Protocol.
• Connect the Cubiscan 325 to a PC using a USB cable (not provided)
through the USB port on the controller box. You will need to load the
USB driver to use this port. Follow the instructions on page 21 to load
the driver.
