SETUP Assembling the Cubiscan 325

Cubiscan 325 14

Loosen the gate stop

1. Loosen the gate stop by turning it counter-clockwise. If you ever want

to lock the gate in place, simply turn the gate stop clockwise until the

gate no longer moves.

Figure 12

Gate stop
