OPERATION Cubing and weighing

Cubiscan 325 31

4. Remove the object from the platform. Wait for the zero indicator to

light before placing the next object on the platform.

5. If the zero indicator does not light, it means that the Cubiscan 325

needs to be zeroed. To zero the scale, make sure that the platform is

free of all objects, then tap [Zero].

NOTE

Do not move the gate too quickly across the platform. A gate speed error is

displayed on the touchscreen if you move it too quickly.

A two-dimensional image of the object shows the top-down view of the

object. An image of the side view of the object appears below the

image of the top-down view. The length, width, height, and weight are

displayed on the touchscreen.

Figure 26

Measuring gate
