OPERATION Cubing and weighing
Cubiscan 325 30
Home
(indicator)
This indicates that the measuring gate is positioned in the “home” position
(on the right-hand side).
Zero (button)
Tap this key to reset the scale to “zero” (make sure the platform is empty).
Refer to “Zeroing the Cubiscan 325” on page 32.
Menu
Tap this key to go to the configuration menu to set up or calibrate the
Cubiscan 325.
Home
Tap this key to return to the home screen.
Measuring/Weighing items
Take the following steps to measure and weigh an item using the
touchscreen. The measuring gate can measure opaque objects as small as
.1 inch (2 mm). An image of the object is displayed on the touchscreen as it
is measured.When you begin measuring with the measuring gate, you must
start with the gate on the right side of the Cubiscan 325, or home position
(indicated by the home indicator on the touchscreen).
You can then use either of the following two methods to measure an
object.
• Place the item anywhere on the glass platform. Starting with the
measuring gate on the right side, or home position, move the gate over
the object, and then move it back to the home position to complete the
measurement.
• Place the item anywhere on the glass platform. Move the gate past the
item that you are measuring to complete the measurement. You can
then remove the item, place another item on the platform, and measure
the new item by moving the gate over it.
1. Verify that the Cubiscan 325 scale is at zero. The zero indicator should
be lit.
2. Place the object on the glass platform. The zero indicator light will go
out.
NOTE
Do not lean on or touch the Cubiscan 325 platform or the object while an object is
being measured. Any kind of contact with the platform during the measurement
process can alter the weight or sensor reading.
3. Using one of the gate movement methods described above, move the
measurement gate slowly using the handle. If the measurement was
successful the length, width, height, and weight of the object are
displayed.
