TROUBLESHOOTING Diagnostics

Cubiscan 325 79

1. From the home screen, tap MENU.

NOTE

If you have set up a password previously in the system configuration, you need to

enter the password to unlock the menu. Refer to page 43.

Figure 74

Home screen
